Brand Name: SENPHUS
Model Number: SHDN
Place of Origin: Jiangsu, China (Mainland)
pipe heating cable
freeze free heating cable
UL,CE,TUV,20w/meter
self temperature 0-10c degree
with plug,convenient
1)Products
Water pipe heating cable
Electric pipe heating cable
Wrap on pipe heating cable
2)Application and Advantages
Water pipe heating cable is designed to prevent frozen condensate pipes in the most extreme conditions,
pipe heating cable is a simple to fit solution which stops frozen, cracked and damaged pipes and ensures
water keeps flowing down to .25C. Once installed Pipe Guard automatically ensures heat is applied to the
pipe when the temperature drops close to freezing, and switches off again to save energy once the pipe has
reached a safe temperature.
PVC insulation pipe heating cable use temperature is -20c degree
Silicon rubber freeze free heating cable use temperature is -60c degree
3)Features
·flexible heating cable,double insulation
·self-temperature control from 0-10c degree
·Ready made unit, simply connect to power supply
·Simple to install, can be quickly zip-tied in place
·Integrated thermostat to ensure energy efficiency
·Monitors pipe temperature, rather than air temperature, to minimise running costs
·Once covered with insulation the entire product is hidden from view, reducing potential damage or vandalism
·Maintenance free and supplied with a 10 year warranty
·Fully earthed for electrical safety
·certificate:TUV,CE,,CSA
Senphus type |
Heated section Length |
Power |
|
With thermostat |
Without thermostat |
M |
W |
SHPT-16-1M-2 |
SHPT-16-1M |
1 |
16 or 17w |
SHPT-16-2M-2 |
SHPT-16-2M |
2 |
32 |
SHPT-16-4M-2 |
SHPT-16-4M |
4 |
64 |
SHPT-16-6M-2 |
SHPT-16-6M |
6 |
96 |
SHPT-16-8M-2 |
SHPT-16-8M |
8 |
128 |
SHPT-16-10M-2 |
SHPT-16-10M |
10 |
160 |
SHPT-16-12M-2 |
SHPT-16-12M |
12 |
192 |
SHPT-16-13M-2 |
SHPT-16-13M |
13 |
208 |
SHPT-16-14M-2 |
SHPT-16-14M |
14 |
224 |
SHPT-16-16M-2 |
SHPT-16-16M |
16 |
256 |
SHPT-16-19M-2 |
SHPT-16-19M |
19 |
304 |
SHPT-16-22M-2 |
SHPT-16-22M |
22 |
352 |
SHPT-16-25M-2 |
SHPT-16-25M |
25 |
400 |
SHPT-16-36M-2 |
SHPT-16-36M |
36 |
576 |
SHPT-16-37M-2 |
SHPT-16-37M |
37 |
592 |
SHPT-16-48M-2 |
SHPT-16-48M |
48 |
768 |
SHPT-16-49M-2 |
SHPT-16-49M |
49 |
784 |
SHPT-16-61M-2 |
SHPT-16-61M |
61 |
976 |
Attention!
Do not cut the heating cable!
Do not install where it can be damaged by game animals.-protect against biting.
Basically do not use tie wrap by installation
Frost-proof water pipes with this heating cable:
calibre |
15mm |
22mm |
28mm |
35mm |
42mm |
48mm |
60mm |
76mm |
Without pipe insulation |
-20°C. |
-13°C. |
-10°C. |
-7°C. |
-5°C. |
-4°C. |
-3°C. |
-2°C. |
With 13mm pipe insulation |
-45°C. |
-45°C. |
-40°C. |
-40°C. |
-35°C. |
-30°C. |
-25°C. |
-20°C. |
